160kva mobile electrical compact complete substation equipment

Nov 03, 2022

ציוד תחנת משנה קומפקטית ניידת 160kva

Box type substations are used in high-rise residential, luxurious villas, square parks, residential areas, small and medium factories, mines, oil fields, and temporary construction electricity and other places to accept and distribute electricity in the distribution system.

Ac metal closed type shift switch cabinet is a three-phase ac 50HZ indoor device metal closed switch equipment.Is used in power plants, substation system rated voltage 35kV, rated maximum current 2000A maximum voltage no more than 40.5kV single bus or single bus sectionalized sets of distribution equipment.

This switch device meets the requirements of DL/ t404-91, IEC298, GB3906 and other standards, and has the functions of preventing wrong operation of circuit breaker, pushing and pulling handcart with load, grounding line, power transmission with grounding line and accidental charging interval (referred to as "five precautions").

Environmental conditions:

גובה: 1000 מ' ומטה.
Ambient temperature: - 25 ~ plus 40 C.

Wind speed: no more than 35m/s.
Arelative humidity: no more than 90 percent ( plus 25 C).
תאוצה אופקית סיסמית: לא יותר מ-{{0}}.4m/s, תאוצה אנכית: לא יותר מ-0.2m/s.
מקום שימוש: לא יהיו חומרים מוליכים, מאובקים, מסוכנים, קורוזיביים, דליקים ונפיצים המזיקים למתכות ולמבודדים.

The European type substation, is a complete set of new power transformer equipment developed by our company on the basis of transformation of national urban network making the optimal combination for the oil-immersed sealed power transformer and high and low voltage electrical components. Through structure optimization, the switchgear shall be miniaturized to extreme extent which greatly reduce the occupied area of the combined transformer with such advantages as small volume, low noise, reliable power supply, reasonable structure, blexible for installation, easy for operation and capable of going deep into the load center to maximum extent, etc.It can assemble network automation terminal (FTU) in the high-voltage ring network cabinet, realize the reliable detection of short circuit and single-phase grounding fault, and has the function of "four remote", which facilitates the automatic upgrade of network distribution. It is widely used in residential quarters commercial centers stations industrial and mining enterprises airports railroads schools hospitals, high-rise buildings and places.

Features:

1) שטח תפוס קטן יותר
2) Firm and reliable
3) קל להזזה, יפה ומעשי
4) העלות שלו נמוכה, ותקופת ההתקנה קצרה

box type substation (4)
